Features and Specifications:
Through the rapid temperature rise can control the temperature, with speed regulation, moisture removal device, suitable for green tea, oolong tea, black tea killing operation; green tea, black tea frying dry operation.
Item | Model |
TS-TDM-60 | TS-TDM-110 | TS-TDM-110DF |
Motor power kw | 0.55 | 1.1 | 1.1 |
Outline dimension
(length*width*height) mm | Coal | 1550*830*1530 | 1915*1350*1910 | 1880*1330*2050 |
Electric | 1550*910*1420 | / | / |
Drum rotation speed r/min | 25±3 | 25±3 | 25±4 |
Output per hour kg/h | ≥5 | ≥16 | ≥200 |
Heating source power | Coal/electric | Coal | Coal |
Electric heat source power kw | 10.5 | / | / |
Fan power kw | 0.08 | 0.37 | 0.37 |
Combustion air fan power | / | 0.12 | 0.12 |
Total weight | 402（coal）302（electric） | 1356 | 1356 |
This product applies in intermittent drying of kinds of famous tea. It is also used to dry food，fruits，melon seeds，peanuts and so on . The use of high temperature to destroy the activity of enzymes in fresh leaves, to prevent polyphenol oxidase from continuing to oxidize, so that the water inside the fresh leaves evaporates. Making the smell of grass in the tea subsides, the fragrance of tea emerges, and the leaves become soft, creates conditions for rolling process.
