Features and Specifications:
This product is one of the drying equipment, using the stove to heat the pot body, tea leaves in the pot to absorb heat, evaporate tea moisture, until drying and forming.
When working, the spatula makes reciprocating movement to exert mechanical force on the tea leaves, and at the same time the wall of the pot generates reaction force on the tea leaves, so the tea leaves are gradually dried round and tightened under the action of reciprocating centripetal thrust of the spatula and a variety of squeezing and kneading forces, and forced to bend into a screw shape or even a sphere.
project | unit of measurement | parameter |
Wok | diameter | mm | 500 |
depth | mm | 230 |
Quantity | piece | 2 |
Fried plate | Fry | ℃ | 75-90 |
Speed | R.p.m | 65-95 |
Heating energy consumption | Electric heating | Not entering the wind | kW·h | 6 |
Strong wind | 7.6 |
Charcoal | kg/h | 0.6/kg dry tea |
Gas type | kg/h | 0.5 |
electric motor | Voltage | V | 380/220 |
power | kW | 0.55 |
Leaf yield | Kg/pot | 4-6 (early bake leaves) |
Moisture content | % | ≤6.0 |
Broken tea rate | % | ≤9.0 |
productivity | kg/h | ≥3.2 |
Dimensions (length × width × height) | Electric heating | mm | 1800×800×1000 |
Charcoal | 1980×960×1000 |
Total Weight | Electric heating | kg | 226 |
Charcoal | 304 |
Operation and use：
(1) machine idle after normal operation, you can heat up the temperature, when the pot temperature reaches the predetermined process requirements, start the motor, frying board, to cast leaves, frying operations. When frying, be sure to master the pot temperature, gross fire (small pot) pot temperature at 90-110 ℃, each pot into the second green leaves (such as the first baked leaves) 4-6kg, full fire (large pot) pot temperature at 60-80 ℃, the amount of leaves per pot 4-6kg (small pot leaves), to be fried tea leaves to reach the shape and dryness required by the process, you can start the pot.
(2) frying, according to the situation can be fried width, speed adjustment, such as hair fire (small pot) or the beginning of the first frying, using high temperature at the same time, using a large gear low speed frying, after the temperature drops to the process requirements, the temperature first high and then low, with the tea leaves lose water enough fire first high and then low, low temperature long frying, small low speed for frying.
In short, according to the various types of curly tea around the quality to show the requirements, process operational requirements and temperature, the amount of leaf input to be the case for reasonable adjustment of the frying width, speed, "see tea do tea".
(3)This product is open tea outlet, no tea door. When the tea comes out, trigger the clutch handle or stop, stop the frying board work, turn the frying board reverse rotation by hand, sweep out the tea leaves from the tea outlet.
(4) Gas type After opening the gas ball valve master switch for two seconds, press the ignition button to ignite the whole burner. After the igniter delayed firing, if the burner is not lit (or not completely lit) that is, close the ball valve switch and re-ignite.
(5) gas type in the end of use, first off the knob switch, then close the ball valve switch, and finally close the gas source main switch.
Transportation, installation and adjustment：
(1) When transporting the double boiler Quemoy frying machine requires smooth placement, not distorted, there should be anti-collision, moisture-proof, anti-extrusion measures, the pot body shall not be placed on sharp and heavy objects, so as not to damage the pot body.
(2) the machine in place requires the ground level, there should not be four feet uneven situation.
(3) The voltage of the power supply must be checked carefully to see if it matches the voltage of the electrical appliances selected for this product, and the ground wire and electric shock protector must be connected properly to ensure the safety of your person and equipment.
(4) Clear the debris in the pot tank and on the surface of the machine, and wipe it clean with a cloth.
(5) Check whether the fasteners are reliable, and tighten the loose fasteners.
(6) Turn on the power to start the machine, for 0.5 hours of air rotation, there should be no jamming, collision and abnormal sound
No jamming, collision and abnormal sound phenomenon.
